Owner(s):
Canadian Pacific Railway 2929
Whyte System Type: 4-4-4
Class: F-1-a
Builder: Canadian Locomotive Company
Date Built: March 1938
Builder's Number: 1943
Cylinders (diameter x stroke in inches): 16.5 x 28
Boiler Pressure (in lbs. per square inch): 300
Diameter of Drive Wheels (in inches): 75
Tractive Effort (in lbs.): 25,900; also reported as 26,000
Tender Capacity:
Coal (in tons): 12
Oil (in gallons): Not applicable
Water (in gallons): 7,700 (Imperial gallons)
Weight on Drivers (in lbs.): 111,000 (another source claims 111,250)
Remarks: Sold June 1959 to Edaville.
From Steamtown NHS Special Study.
To see No 2929 in happier days click HERE
